Quick Die Change    Hydraulic and Mechanical Clamps   Die Rollers    Hydraulic Die Lifters   PLC Controlled Systems   Bolster Extensions    Modular Die Carts    Die Racks

Click here to visit PFA Aerostar's Website: astar.com

Clamps


Model 200



Model 203 Model 425 Model 126





10,000 lbs of clamping force @5000 psi.

Shown with mechanical lock and stud/T-nut.



26,000 lbs of clamping force @5000 psi. Shown with mechanical lock.



This Rocker Clamp generates 8000 lbs. of clamping force @5000 psi.

Shown with mechanical lock.



This rocker clamp used in a variety of clamping applications and generates 22000 lbs. of clamping force @ 5000 psi hydraulic pressure.




Die Lifters
Hydraulic Mechanical

Heavy duty die lifter roller allows easy movement of heavy dies.

Lifting capacity per rail:

42" length = 10000 lbs;

48" length = 12000 lbs;

60" = 16000 lbs



Available in various lengths. For use in T-slots sized from ..812/.875 to 1.03 wide and minimum 1.50 deep.

Each rail lifts 1500 lbs per linear foot @5000 psi



Mechanically actuated - 4000 lbs. lifting capacity.

Roller bearings are down for travel with the die.



4000 lbs. of lifting capacity. Leverage provided by the handle varies with angle and is in the range of 80 to 40:1.




Standard 4-circuit controller PLC Controller
Each hydraulic circuit is controlled by a manually turned valve. Each valve contains a check valve.

A pressure sensor is included when applications requires communication of low pressure to press controls.



Stationary, three PLC controlled electrically actuated valves. These pumps are used as described above. Two, three and four circuit pumps are available.
